Robot safety: top tips for working alongside robots

Darren Whittall, technical manager at FANUC UK, explains why worker safety should be a top priority in all robotic applications and the steps you can take to avoid robot-related accidents when humans are sharing the same workspace.

1. Scope out all potential hazards – Safety risks will vary depending on your chosen robot and application. Start with a well-documented risk assessment. It’s worth noting that most robot-related accidents occur during non-routine operating conditions, e.g. operators entering the cell for programming, maintenance, testing, setup, or adjustment tasks.
2. Revisit the regulations – The Health and Safety Executive (HSE) offers industrial robot safety guidance in theHSG43, Industrial Robot Safety publication. International standards are set out in EN ISO 10218 – Part 1 Robots and robotic devices – Safety requirements for industrial robots, while EN ISO 10218 – Part 2 goes into more detail about robot systems and integration.
3. Use simulation software to plan out and test robotic concepts – As well as flagging potential new-build issues, software, like FANUC UK’s ROBOGUIDE, can model all of the variable robotic movements, obstacles and potential collision scenarios, in a 3D virtual world.
4. Introduce safeguards - Seek expert guidance when building a safety related control system (SRCS) early in the design phase, as there are many different concepts to consider, including whether your SRCS should be a dedicated system or integrated within your robot controller or robot safety software.
5. Provide employees with clear instructions – Reduce the risks of incidents by ensuring your employees receive regular operator training and are issued with appropriate personal protective equipment (PPE).
6. Consider the cost benefit and effectiveness of software-enabledtechnology – Commonplace in the automotive sector, having less hardware means that safety can be integrated more cost-effectively – up to 50% cost-reduction is possible for a small single robot with multiple safety devices. FANUC’s latest DCS software can monitor the robot’s position and speed. The removal of limit and zone switches also makes work cell configurations tighter and simpler.
7. Create adaptive zones – It is now possible to programme, enable and disable the zone that the robot can or can’t enter, depending on the task in-hand. This feature, available through DCS Position Check, is especially useful for compact cell configurations.
8. Define maximum robot speed – This can be done during normal operation or adjusted to a defined event, enabling an operator to work safely within the proximity of the robot. FANUC’s DCS Speed Check monitors the speed of the robot, ensuring the whole robot, including the end-effector, remains motionless when required.
9. Compliance with machine safety standards – Check whether your system meets the PL (performance level) safety standards specified in BS EN ISO 13849-1. As a benchmark, FANUC’s DCS Position and Speed Check functions are certified to PL d and Safe IO Connect to PL e.
10. Stay on top of your safety requirements - In today’s fast-paced manufacturing environments, robotic work cells and plant layouts evolve quickly. It means constantly revisiting and modifying your safety considerations. With software being more flexible and simpler to upgrade and integrate, this is when a software-based robot comes into its own.
