Transmit data and power for robotics up to 100m
Motion control equipment manufacturer Stober has further developed its One Cable Solution (OCS) so that users can now connect motors and drive controllers at distances of up to 100m.
Designed in collaboration with encoder expert Heidenhain, this new single cable connection means that machine builders no longer need to use two cables to power the motor and transmit encoder data. It can all be done with this one new hybrid cable from Stober.
Countless lab tests over continuous operation have revealed that the quality of the data transmission enabled all signals to be read and evaluated flawlessly without errors in the encoder communication, even after five million cycles. The new OCS also eliminates data transmission weakness and removes the need to use an output choke up to 50m. For axes above 50m Stober supplies a choke.
Stober’s new OCS is compatible with the Stober SC6 and SI6 drive controllers, which are suitable for powerful drive systems and highly efficient multi-axis applications. Stober has also enhanced these two drive controllers with a new series transceiver chip, as used in Heidenhain’s EnDat 3 encoder, which makes the company the first drive specialist on the market to use the OCS in combination with this encoder solution.
The OCS is designed for use with Stober’s EZ and EZS series synchronous servo motors, which can also be combined with all Stober gear units in direct attachment, enabling engineers to design much more compact solutions.
Consequently, customers benefit from maximum data transmission quality, full diagnosis, safety and performance, which is ideal for digital production and robotics.
