Schaffner introduces EMC filter series for robotics

220531_SchaffnerSchaffner announces the availability of the new FN2500 and FN2640 EMC filter series for robotics applications. The new filters have been developed to meet the specific needs of this important and growing market.

Many robotics applications require power supplies to be mounted in 19” rack cabinets. To accommodate this and provide systems builders with seamless integration Schaffner has packaged the FN2500 / FN2640 EMC filter series in a space saving 1U rack-mount design.

The new FN2500 and FN2640 EMC filters are available with a range of connection options. These include IEC C14 (10-15A) or IEC C20 (16-20A) input connectors for direct mains connection and with a range of output connectors. For internal assembly connection options available on input and output include push-on terminals, cable glands, screw terminals or spring terminals.

Key standard features include input voltage 250 VAC at DC to 60 Hz, output current 10 to 20 A at 40°C, MTBF better than 300,000 hours and operating temperature range -40°C to +100°C (with derating >40°C).

Visit the Schaffner website for more information
